Loading Bays Australia
Loading Bays Australia
designed with
30 years experience to keep your project moving.
Now offering the Guardian Gantry System
SERVICES
Loading Bays
Problem-solved by design, our rolling bays are designed to keep your job moving, saving time and promoting safe working practices through functionality.
Lift Shaft Builds
Lift shaft builds to suit requirements
Loading Bay Transport
With transport organised in-house, you can be assured your delivery is our priority.
New Service
Guardian Gantry System
Why choose Guardian Gantry Hire for your next project?
• Our Guardian Gantry modular overhead protection system has been designed and engineered to provide a minimum 10 kpa rating.
• Quick efficient installation and dismantle. • Site sheds and scaffold can be installed on top of gantry.
• Material can be loaded on top of gantry. All our gantry’s are rated above 10 kpa.
• Guardian Gantry has superior leg spanning capabilities up to 10.000 meters. • Versatile and adaptable for most site locations, both indoors and out.
• Ideal for forming tunnelled protective walkways.
Value Added and Standard Features.
• The Guardian Gantry System is 2.500 metres wide and comes in modules of 2.500, 5.000 and 7.500 meters in length. Gantry modules can be bolted together to provide superior leg spans of up to 10.000. • The Guardian Gantry System has been designed to house site sheds with 1.600 wide, 1.250 wide and .300 wide cantilevers installed to achieve a 4.100 metre wide overall platform.
• The Guardian Gantry System is fully height adjustable and can be set at a total height of 4.800 metres clearance for vehicle access bays.
• Vehicle access gates, personal gates and 1.000 metre wide stair access can be provided as an option.
• Ply Hoarding can be installed to our Guardian Gantry system to one or both sides for site protection.
• High Profile Finish. All of our Guardian Gantry Products we hire come to site in perfect condition, freshly painted white or your company colours.
• For more difficult projects Guardian Gantry can design and customise a structural gantry to suit your requirements.
Ask how we can assist you with your gantry needs today
​
Multi Level Gantry
The Guardian Gantry system shown in these pictures is designed and engineered to form a link between two 25 storey buildings under construction in Elizabeth Street, Brisbane.
The double material hoist is attached to the side of the gantry ensuring a smooth efficient supply of materials to each level.
The gantry is fully encapsulated with mesh screens supplied and installed by Guardian Gantry to ensure the safety of the workers using the hoist and gantry link.
ABOUT LOADING
BAYS
AUSTRALIA
Necessity is the mother of invention, Loading Bays Australia design features come from an in depth understanding of the issues that are faced during the construction process and has innovated and problem solved by design leading to a bay that provides for streamlined functionality, enhancing time efficiency and safety of operation.
​
Loading Bays Australia’s design facilitates straight forward lifts for your crane and crane crew, and straight forward loads on and off the bay enhancing safety and speed of operation; our patented design is geared for maximising crane time productivity.
​
Loading Bays Australia is able to meet any onsite install requirements to suit the slab.
Loading Bays Australia offers builds for lift shafts.
Loading Bays Australia is Australian owned, designed and manufactured to Australian standards through every stage of development and production.
